E Plate For Disc Brake

A.C. Disc Brakes (Fail Safe): Very Compact and modern in design foundation is not necessary as they are directly mounted on non driving end shaft of the motor. It consist of liner plates Brake disc with square hole at the center. One corresponding piece of square hub is supplied with the brake. This hub is keyed to the motor shaft and the liner plate is free on this hub normally line plate is gripped between two discs with the help of spring pressure. They work on 230/115 V AC when the current is supplied to the brake, one disc is attracted by electromagnet against spring pressure and the liner plate is released. Thus the brake is off. Once the brake is set it dose not required adjustments or maintenance. When the liner plates wears with the use then only air gap is to be maintained periodically. An arrangement to release the brake manually could be provided on request.
